Mineral Processing Screens
Mineral processing screens is a metal mesh structure element used for screening and filtering. It is used in screening, filtering, dehydration, desludging and other operations. It has high strength, rigidity and load-bearing capacity, and can be made into rigid screening and filtering devices of various shapes. It is easy to leak, wear-resistant and corrosion-resistant.
- Product Introduction
Product Parameters
|
Material |
High-manganese steel, 65Mn spring steel, stainless steel, or surface-welded wear-resistant layer. |
|
Wire diameter |
Common range: 3.0mm - 12.0mm |
|
Mesh size |
Common aperture sizes: 3mm - 150mm. Square or rectangular holes, customizable according to equipment drawings. |
|
Weaving method |
Featuring a high-strength plain weave for structural stability; the reinforced embossed weave prevents clogging and enhances wear resistance. |
|
Screen mesh size |
Customization is our main focus; please provide the screen machine model or precise dimensions such as length, width, and arc length in the form of drawings. |
|
Connection method |
Edge welding, hook-type fastening, bolt tightening, etc., must be matched to the sieve frame structure. |
|
surface properties |
It can be subjected to quenching or surface hardening treatment to improve wear resistance and service life. |
Product Features
Mineral screen is a newly developed product in wire mesh industry. Mineral screen includes polyurethane screen, manganese steel mineral screen and stainless steel mineral screen. It has high screening rate, wear resistance, corrosion resistance, anti-skid, vibration resistance, strong elasticity, strong toughness and no close together. The cross section of the wire is trapezoidal. The gap is narrow at the top and wide at the bottom. It is a screen bar made of cold-rolled stainless steel wire, and the support bar is welded by automated mineral screen production equipment. The screen gap is uniform, the welding quality is stable, the opening rate is high, the service life is long, it has high strength, rigidity and bearing capacity, and can be made into various shapes of rigid screening and filtering devices.
Applications
Petroleum and Chemical Industry
As a petroleum filter, filtering oil impurities; separating granular materials in fertilizer production.
Mining and Coal
Screening ore and coal particles, separating mineral resources of different particle sizes.
Grain and Salt Industry
Screening grain crops and salt particles to remove impurities.
Frequently Asked Questions (FAQ)
1. Q: Do you support customized processing of products?
A: Yes, we support customized processing services. The company can provide personalized design and production of various wire mesh products according to your specific needs, including adjustment of size, material and performance parameters.
2. Q: Can I apply for sample testing?
A: Yes. We provide samples of some products for testing. Please communicate with our sales department to confirm the specific types of samples that can be provided and the delivery process.
3. Q: How long is the delivery cycle of conventional products?
A: For standard products, they are usually shipped within 7-15 working days after the order is confirmed. The production cycle of customized products is longer, and the delivery time is about 20-30 working days.
We are not only a manufacturer of Mineral Processing Screens but also a solution provider for mining screening applications. From material selection and structural design to wear-resistant treatment, mass production, and quality verification, we have established a closed-loop capability, enabling us to provide foreign mining customers with highly durable and adaptable products and fast, reliable supply guarantees.
High Wear-Resistant Material Processing and Treatment Capabilities:We are equipped with professional high-carbon steel and high-manganese steel wire drawing and heat treatment production lines, capable of processing high-hardness raw materials (such as high-manganese steel wire with a Brinell hardness of over HB200). We can also perform overall quenching or surface wear-resistant strengthening treatment on finished screen meshes, making them suitable for heavy-duty ore screening scenarios requiring high wear resistance.
Heavy-Duty Precision Weaving and Deep Processing Equipment:We possess heavy-duty large-diameter wire weaving machines and supporting high-precision stamping and welding equipment, enabling us to stably produce reinforced mining screen meshes with wire diameters up to 12mm. We can perform precise edge welding, hook manufacturing, and irregular cutting according to drawings, ensuring assembly compatibility with various vibrating screens.
Engineering Design and Rapid Response:Backed by a team of over 20 engineers, we provide non-standard design and drawing conversion services. Customers only need to provide the screen machine model or working condition parameters (material, particle size, output), and we can complete the structural design and load calculation of the screen mesh, providing technical solutions and drawing confirmation within 3-5 working days.
Scaled Production and Flexible Supply:For conventional materials and specifications of Mineral Processing Screens, we can guarantee a stable supply capacity of tens of thousands of square meters per month. For the concentrated demand of large-scale mining projects, we can initiate special production scheduling, possessing the capability to complete the production and stocking of single orders of tens of thousands of square meters within 20-30 days.
Targeted Quality Verification System:In addition to ISO 9001 system process control, we have established specialized testing: using wear testing machines to simulate working conditions for wear testing; performing metallographic analysis on materials such as high-manganese steel to ensure that the heat treatment process meets standards; and conducting uniform tension testing on finished meshes to verify their fatigue resistance and ensure structural integrity during long-term vibration.
